Axial Flow Check Valve, BS 1868, 2-36 Inch, Class 150-2500 LB
Key Specifications / Features
Model no.: JSC-231124-WCV-88
Hits: 21
As a reputable fabricator in China, we specialize in manufacturing axial flow check valves in accordance with BS 1868 and ASME B16.34 standards. Our versatile range covers sizes from 2 to 36 inches, catering to Class 150-2500 LB specifications. Crafted from cast carbon, alloy, and stainless steel, our axial flow check valves are designed for non-slam operation, ensuring reliable performance across various applications.
Request a quote
Tags
Detail Information
Axial Flow Check Valve
Axially guided valve disc held against the seat by spring and back pressure. When the upstream fluid force is greater than the spring force, the disc will move axially off. The contoured body-disc-diffuser arrangement assures venturi flow characteristics ensuring minimal pressure drop across the valve and steamlined axial flow.
Axial Flow Check Valve-Features
1. Efficient streamlined Axial flow
2. Integral diffuser
3. Disc easy opening and stability
4. Tilting disc check valves
5. Piston check valves
6. Non-slam operation
Axial Flow Check Valve-Specifications and Standard
Design and Manufacture: BS 1868 or ASME B16.34
Inspection and Test: API 598
End flange dimension: ASME B16.5, ASME B16.47 (API 605, MSS SP-44)
BW end dimension: ASME B16.25
Face to face, end to end: ASME B16.10
Pressure-temperature ratings: ASME B16.34
NACE: NACE 0175
Size Range: 2 Inch – 36 Inch
Pressure Range: ASME Class 150 – 2500 LB
Materials: ASTM A216 WCB, WCC, ASTM A217 WC1, WC6, WC9, ASTM A351 CF8, A351 CF8M, A351 CF3, A351 CF3M, A351 CN7M, ASTM A352 LC1, LCB, LCC, LC3, Hastelloy C276, Monel, Titanium and Alloy 20 (Cast Steel, Alloy Steel, Stainless Steel, Special Steel)
Axially guided valve disc held against the seat by spring and back pressure. When the upstream fluid force is greater than the spring force, the disc will move axially off. The contoured body-disc-diffuser arrangement assures venturi flow characteristics ensuring minimal pressure drop across the valve and steamlined axial flow.
Axial Flow Check Valve-Features
1. Efficient streamlined Axial flow
2. Integral diffuser
3. Disc easy opening and stability
4. Tilting disc check valves
5. Piston check valves
6. Non-slam operation
Axial Flow Check Valve-Specifications and Standard
Design and Manufacture: BS 1868 or ASME B16.34
Inspection and Test: API 598
End flange dimension: ASME B16.5, ASME B16.47 (API 605, MSS SP-44)
BW end dimension: ASME B16.25
Face to face, end to end: ASME B16.10
Pressure-temperature ratings: ASME B16.34
NACE: NACE 0175
Size Range: 2 Inch – 36 Inch
Pressure Range: ASME Class 150 – 2500 LB
Materials: ASTM A216 WCB, WCC, ASTM A217 WC1, WC6, WC9, ASTM A351 CF8, A351 CF8M, A351 CF3, A351 CF3M, A351 CN7M, ASTM A352 LC1, LCB, LCC, LC3, Hastelloy C276, Monel, Titanium and Alloy 20 (Cast Steel, Alloy Steel, Stainless Steel, Special Steel)
